Technical features
Maximum operating pressure 10 – 16 bars
Maximum operating temperature110°C / 140°C
Plate materialAISI 316 L stainless steel
Fittings materialAISI 304 / AISI 316 L
Water side fittingsG2
SealsEPDM (max 140°C) – NBR (max 110°C)
Number of plates7 – 125
Measurements and weights
Frame length340mm
Frame height780 mm
Frame thickness 25 / 30 mm
Plate thickness0.5mm
Exchange surface0.1300 m² / plate
Rods350 mm (7 – 51 plates)
 550 mm (53 – 75 plates)
 650 mm (77 – 125 plates)
Plate distance3.3mm
Connection distance604 / 145 mm
Weight Z3 mod. 10 bars(114 + 0.8 x N) kg*
Weight Z3 mod. 16 bars(140 + 0.8 x N) kg*

*Data subject to tolerance.
